Retrofit Surface Mounted Patio Door Handle and Lock Set

This set is a surface-mounted handle and locking mechanism for inline sliding patio doors that replaces obsolete handles and locks without the need for morticing.

Key Features

• Fully reversible
• Surface-mounted lock, keep and handle set requiring no morticing
• 2 opposing direction hooks to help prevent lifting
• Hooks cannot be thrown unless the door is closed
• 95mm cylinder bar to suit most door thicknesses
• Finish options: Black or White
• Supplied as a handle and lock set with 2 keys.

• Screw Centres: 122mm
• Flat Bar Length: 95mm
• External Body Length: 175mm
• External Body Width: 33mm
• External body Projection: 33mm
• Internal Body Length: 175mm
• Internal Body Width: 33mm
• Internal Body/Handle Projection: 60mm
• Keep Length: 187mm
• Keep Width: 19mm
• Keep Projection: 18mm
